USB Tester KWS-MX18L is a universal voltmeter and ammeter that allows you to measure voltage, current, battery capacity and charging time in real time. Thanks to the color LCD display with four information display options, you can easily monitor the charging process of your devices.
Characteristics
-
Model: KWS-MX18L
-
Manufacturer: KWS
-
P/N: KWS-MX18L
-
Voltage measurement: 3.60-32.5 V (step – 0.01 V)
-
Current measurement: 0-5.00 A (step – 0.01 A)
-
Capacity measurement: 0-99999 mAh (step – 0.001 mAh)
-
Power measurement: 0-299.99 W (step – 0.001 W)
-
Measurement of lost energy: 0-999.999 Wh (step – 0.001 Wh)
-
Internal resistance measurement: 0-999.9 Ohm (step – 1 Ohm)
-
Charging/discharging time measurement: 0 seconds – 999 hours (step - 1 second)
-
Display update rate: once/500 ms
-
Dimensions: 65*24*14 mm
-
Net weight: 19 g
-
Color: black
-
Display color: IPS color
Equipment
Part number:
78504
